Description JBD Smart BMS 10-17S 60A (SP17S005) Charge and discharge are both at the same port Product Data Sheet Cell specifications: 10~17 strings of Lithium Iron Battery Interface type: Charge and discharge are both at the same port Charging voltage: 4.20V*Number of strings Cell voltage range: 2.8~4.25V Continuous charging current: 60A Continuous discharging current: 60A Consumption of running: ?10mA Consumption of sleep: ?500uA Circuit resistance: ?10mR Operating temperature: -30�C~75�C The JBD SMART BMS 60A SP17S005 (10-17S) is an advanced Battery Management System designed for lithium-ion and LiFePO4 battery packs with 10 to 17 series cells. It supports a continuous discharge current of 60A, making it suitable for moderate to high-power applications such as electric vehicles, solar energy storage, and backup power systems. The BMS features critical protection functions, including overcharge, over-discharge, overcurrent, short circuit, and temperature safeguards to ensure the safe operation of the battery. It also incorporates active cell balancing to maintain voltage consistency across all cells. With support for UART, RS485, and CANBUS communication, as well as Bluetooth connectivity for real-time monitoring, the system offers flexibility and reliability for a variety of applications.
